SV-CAM9LR

The SV-CAM9LR is a flexible universal fit camera with CVBS resolution to compete at a price. The CAM-9LR is a universal fixed angle reversing camera, designed to fit most cars and vans. Featuring a 1099 image sensor, 976 x 496 pix resolution and 700 TV lines the camera provides a full colour high def image for the driver. The CAM-9LR is also IP68 rated, meaning it is protected against all standard weather conditions and will continue to operate in temperatures ranging from -20 degrees C to +75 degrees C.

• Image Sensor: 1099
• TV Lines: 700
• Resolution: 976 x 496
• Minimum Illumination: 0.1 Lux
• TV System: NTSC
• Waterproof Rating: IP68
• Horizontal Angle: 170 Degrees
• Vertical Angle: 120 Degrees
• Parking Lines: Yes (Removable)
• Image Adjustment: Yes (Mirror/Normal)
• Enhanced Performance In Low Light: Yes
• Operating Voltage: 12V DC (Negative Ground)
• Current Consumption: 48mA @ 13.8V
• Operating Temperature: -20 Degrees C to +75 Degrees C
